VB2 Ethanol Burner



Burner designed to convert traditional fireplaces.

Whether an Edwardian, Federation, Art Deco or Art Nouveau fireplace, the VB2 has been designed to be easily integrated into existing fireplaces. The minimalist design mean you can easily convert an older style fireplace into a clean-burning bioethanol fire.



Key Features



Easily placed

Simply place the purpose-designed stainless-steel burner within the grate in the fireplace.



Adjustable feet

The burner can be levelled and lifted to the best setting, depending on the depth of the grill it’s being placed within.



Built to last

The VB2 has several layers of internal features that increase its efficiency including vertical baffles, aspiration vents and dense padding – all of which are dishwasher proof.



Monochrome hue

VB2 is finished in black, super high temperature powdercoat, designed to blend with existing fireplaces.



Dedicated filling point

A designated, inbuilt filling point decreases the likelihood of overfilling.



Minimal maintenance

A simple lid is used to extinguish the flame and cover the burner opening when not in use, preventing dust or debris from falling into the tank, leaving it clean and safe for year-round use.



Construction

WEIGHT - 1.8kg [4lb]

MODEL DIMENSIONS mm [in] - L 330mm [13in]W 110mm [4.3in]D 113mm [4.4in]

APPLICATION - Indoor

MATERIALS - Stainless Steel Grade 304



VOLUME CAPACITY

2 L

0.5 Gal

HEATS ON AVERAGE

15m2

161ft2



MINIMAL ROOM

45m3

1589ft3



THERMAL OUTPUT

6180 BTU/h

2.5 kW 7.2 MJ/h



BURN TIME

6h

2 Litres
